Red Dragon« X skimmer pump 60 Watt / 2500 l/h for BK DC - SM - DL 250 + 300

Red Dragon« X skimmer pump 60 Watt / 2500 l/h for BK DC - SM - DL 250 + 300
For a larger view click on the thumbnail
Red Dragon« X skimmer pump 60 Watt / 2500 l/h for BK DC - SM - DL 250 + 300
Red Dragon« X skimmer pump 60 Watt / 2500 l/h for BK DC - SM - DL 250 + 300
Red Dragon« X skimmer pump 60 Watt / 2500 l/h for BK DC - SM - DL 250 + 300
Red Dragon« X skimmer pump 60 Watt / 2500 l/h for BK DC - SM - DL 250 + 300
Red Dragon« X skimmer pump 60 Watt / 2500 l/h for BK DC - SM - DL 250 + 300
Red Dragon« X skimmer pump 60 Watt / 2500 l/h for BK DC - SM - DL 250 + 300
Red Dragon« X skimmer pump 60 Watt / 2500 l/h for BK DC - SM - DL 250 + 300
Red Dragon« X skimmer pump 60 Watt / 2500 l/h for BK DC - SM - DL 250 + 300
Red Dragon« X skimmer pump 60 Watt / 2500 l/h for BK DC - SM - DL 250 + 300
424.95 USD
Model
Add to cart

Shipping time: 3-4 Days
Product no.: 7120/S/1


Products description

Red Dragon® X skimmer pump 60 Watt / 2.500 l/h
with 24V Technology
for Bubble King® Double Cone 250 + 300
for Bubble King® SuperMarin 250 + 300
for Bubble King® DeLuxe 250 + 300

AND for VERTEX ALPHA 250 + 300 (choose BK DC 250 or 300)

Technical data Red Dragon® X DC skimmer pump:

With needle wheel
adjustable DC-pump with 24V / 60W

Delivery rate: 500-2.500 l/h  Air inlet ~ 600-6.500 l/h Water inlet
wattage power: Pmax = 60 Watt/h
Speed adjustable Brushless DC pump
Revolution per minute (rpm) - Display
Adjustable in 8-steps from ~ 8W up to 63W
Operating voltage: 100-240 Volt 50-60 Hz (24V Technology)
Protection class pump: IP 68  control unit: IP 66
Weight pump without controller: 1,25 kg
Height of intake side: center 45 mm
Dimension pump: 90 mm wide / 150 mm length / ~ 130 mm height
Dimension control unit: 30 mm wide / 95 mm length / ~ 105 mm height

Suitable for:
für Bubble King® Double Cone 250 + 300
für Bubble King® SuperMarin 250 + 300
für Bubble King® DeLuxe 250 + 300
​​​​​​​

Delivery with suitable connection piece
Silicone-decoupling-connection-pieces 32mm

pdf_icon  RDX Skimmer Pump - Operating_and_maintenance_manual.pdf

//////////////////////////////////////////////////////////////////////////////////////////////////////////////////

  • Saltwater resistant M4 grade 2 titanium screws
  • Saltwater resistant parabolic rubber feet for acoustic decoupling
  • Extreme low noise brushless DC-delivery pump with external power electronics
  • High efficient technology, Sine Wave for very quiet running
  • Inlet and Outlet complete with DIN connection, compact dimensions
  • Easy usage and maintenance, low risk of calcification
  • compact design against vibrations and oscillation
  • CE conformity, developed and built
  • high quality touchscreen display with feeding function
    (protection against dry-running, over heating, over voltage, blocking etc.)
  • included in the scope of delivery:
    • Pump with 2m supply line
    • Controller with 1,5m supply line
    • Power plug with 1,5m supply line / rubber connector
    • with inlet protection
    • with 20mm socket and 25mm socket with O-rings
    • Manual German/English
